Details
Model |
Capacity @ LC (kg @ mm) |
Mounting Class
|
Carriage Width (mm) |
Opening Range (mm)
|
Fork Pocket Width (mm) |
Lost Load (mm) |
Unit Weight (mm) |
TJC25-1020 |
2500 @ 600 |
II |
1020 |
250-880 |
100-125 |
62 |
64 |
TJC25-1200 |
2500 @ 600 |
II |
1200 |
250-1060 |
100-125 |
62 |
71 |
TJC35-1070 |
3500 @ 600 |
III |
1070 |
285-958 |
100-125 |
64 |
85 |
TJC35-1200 |
3500 @ 600 |
III |
1200 |
280-1082 |
100-125 |
64 |
128 |
NOTES:
• Two additional hydraulic circuits required
• Sideshifting range: +/- 100mm
• Opening range refers to the distance between the fork’s outer edges
• Tines and hoses not included
• Maximum 1520mm fork length can be fitted, contact us if fork lengths above 1520mm required
• Please contact the forklift manufacturer for the residual capacity of attachment
• Further technical details available upon request, please call 1800 061 998
